UMapx sub-library for plotting data on Windows

Installation

Install UMapx.Visualization using NuGet:

dotnet add package UMapx.Visualization

The package includes dependencies on UMapx and System.Drawing.Common, which NuGet restores automatically. The public API is in the UMapx.Visualization namespace.

Quick start

Plot a series of values and save the figure as a PNG image:

using System.Drawing;
using System.Drawing.Imaging;
using UMapx.Visualization;

using var style = FigureStyle.Standard;
var figure = new Figure(style)
{
    Title = "Quadratic function",
    LabelX = "X",
    LabelY = "Y"
};
figure.Grid.Show = true;
figure.Plot(new PlotSeries(
    new[] { -2f, -1f, 0f, 1f, 2f },
    new[] { 4f, 1f, 0f, 1f, 4f },
    2, Color.RoyalBlue, SeriesType.Plot, ShapeType.Circle, "y = x²"));

using var bitmap = new Bitmap(800, 600);
figure.To(bitmap);
bitmap.Save("plot.png", ImageFormat.Png);

The examples use C# 9 or later and write images to the current working directory. Figure.To(bitmap) renders into the supplied bitmap; Figure.To(graphics) renders into an existing System.Drawing.Graphics surface.

Plotting and drawing

Component	Purpose
Figure	Cartesian plots with titles, axis labels, automatic or manual ranges, and bitmap display
PlotSeries	X and Y samples, line width, color, marker shape and legend label
SeriesType	Line plots (Plot), stem plots (Stem) and scatter plots (Scatter)
FigureStyle	Colors, fonts and line widths, with presets such as Standard, MATLAB, MathCad, Excel and Black
ShapeType	Circle and rectangle markers, with outlined and filled variants
Grid, Legend	Grid patterns, axis marks and legend position, spacing and appearance
Painter, PaintData	Rectangles, titles, text labels and points drawn over images

Axis ranges and tick counts use RangeFloat and PointInt from UMapx.Core.

Platform support

The library targets .NET Standard 2.0 and builds as AnyCPU. Drawing uses System.Drawing.Common and requires Windows. Linux and macOS are not supported by this rendering backend.

Regression tests cover Windows with .NET 8 in an x64 process.

Working with figures

PlotSeries accepts float[] arrays. X and Y must have equal lengths. The constructor that takes only Y values generates X coordinates starting at zero. Call Figure.Plot() for each series to display several series on the same axes. The figure retains the supplied series and arrays; it does not copy their data.

AutoRange is enabled by default. Ranges are calculated when the figure is rendered, using the finite values across all series. Constant values receive a margin so that single points and constant signals can be displayed. To set fixed bounds, disable AutoRange and assign RangeX and RangeY using RangeFloat.

Set Marks with PointInt to choose the number of intervals on each axis. Enable the grid with Grid.Show and choose solid, dashed or dotted lines with Grid.Style. The legend is visible by default; use Legend.Show to hide it or Legend.Anchor to change its corner. Each series supplies its legend text through PlotSeries.Label.

Figure.Image(bitmap) displays a bitmap inside the plotting area and sets the axes to its dimensions, even when AutoRange is disabled. It retains the bitmap; keep it alive until rendering is complete. Clear() removes all series and the image, and resets both axis ranges to [-5, 5].

Dispose FigureStyle after the last render, and dispose bitmaps and graphics objects when finished. A figure does not take ownership of these resources.

Image annotations

Draw a labeled rectangle and points on a blank image:

using System.Drawing;
using System.Drawing.Imaging;
using UMapx.Visualization;

using var bitmap = new Bitmap(640, 360);
using (var graphics = Graphics.FromImage(bitmap))
using (var painter = new Painter { InsideBox = true, Transparency = 40 })
{
    graphics.Clear(Color.White);
    painter.Draw(graphics, new PaintData
    {
        Title = "Object",
        Rectangle = new Rectangle(120, 80, 320, 220),
        Labels = new[] { "Confidence: 0.98" },
        Points = new[] { new Point(220, 180), new Point(340, 180) }
    });
}
bitmap.Save("annotations.png", ImageFormat.Png);

To annotate an existing image, load it with new Bitmap("input.jpg") and omit graphics.Clear(). Painter.Draw() draws directly onto the supplied graphics surface and accepts multiple PaintData objects in one call. Painter owns its pens and font and disposes them with the painter; the caller owns the image and graphics surface.

Build and test

Run from the repository root on Windows with the .NET 8 SDK, or a newer SDK with the .NET 8 runtime installed:

dotnet build UMapx.Visualization.sln -c Release
dotnet test UMapx.Visualization.sln -c Release --no-build --no-restore

The solution contains the library and its tests. Dependencies are restored from NuGet during the build. build.bat builds the library in Release configuration.

Tests cover automatic ranges for constant and single-point series, combined bounds across multiple series, manual ranges, and empty or nonfinite data. They are also discoverable in Visual Studio.

Build outputs:

• Library and XML API documentation: sources/bin/Release/netstandard2.0/.
• NuGet package: sources/bin/Release/UMapx.Visualization.*.nupkg.

License

MIT
